Colorado Time System Mini Electronic Scoreboard

FREE SHIPPING DOES NOT APPLY FOR SPECIAL ORDERS

This smaller electronic scoreboard is an affordable solution for clubs and smaller facilities. The Mini LED Electronic Scoreboard from Colorado Time Systems provides the best of both worlds: it provides the same information as two lines from the LED-R Electronic Scoreboard at a quarter of the size. The Mini Electronic Scoreboard contains two lines of digits that can be configured in a multitude of ways to fit your needs for swimming, water polo, synchronized swimming, and track.

Features:

• Includes legs and handle for easy portability
• Tripod or wall mountable
• Optional battery operation
• Can be stacked to create multi-line auxiliary electronic scoreboard, or entry-level electronic scoreboard solution
• Viewing distance: at least 50 m
• Displays data through CTS Systems 6, 5 and 4000 as well as pace clock controller (UPC-C)
• Compatible with the Dolphin system through the Dolphin Scoreboard Adapter

Specifications:

• Dimensions Height: 13.75” (34.9 cm) Width: 48” (121.9 cm) Depth: 4” (10.2 cm)
• Viewing Distance Over 50 meters Digit Size 5” (12.7 cm)
• Data Connection Standard CTS data cables (2 DC). Please specify length when ordering.
• Data Source System 6 System 5 and System 4000 (Must be set to high speed data) Pace Clock Controller The MiniLED Scoreboard is compatible with the Dolphin system through the Dolphin Scoreboard Adapter, as described in a separate data sheet.

Options:

• Top line displays Event/Heat - Bottom line displays Lane-Place-Time (P01-0001)
• Top and bottom lines display Lane-Place-Time (P01-0002)
